| Camera |
| Image Sensor: |
| |
1/1.9″ HD CMOS sensor |
| Effective Pixels: |
| |
1920(H)x1080(V) |
| Signal System: |
| |
PAL/NTSC |
| Minimum Illumination: |
| |
Color: 0.002 Lux @(F1.5, AGC ON)
B/W: 0.0002 Lux @(F1.5, AGC ON) |
| White Balance: |
| |
Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC: |
| |
Auto/Manual |
| BLC: |
| |
ON/OFF |
| HLC: |
| |
Support |
| Smart defog: |
| |
Support |
| WDR: |
| |
120dB |
| Shutter Time: |
| |
1/1 s to 1/30,000 s |
| Day& Night: |
| |
ICR |
| Digital Zoom: |
| |
16× |
| Privacy Masking: |
| |
24 privacy masks programmable; optional multiple colors and mosaics |
| Auto Focus: |
| |
Auto / Semi-automatic / Manual |
| Lens |
| Focal Length: |
| |
5.9 mm to 135.7 mm, 23× optical zoom |
| Zoom Speed: |
| |
Approx. 7.4 s (Optical Lens, Wide-Tele) |
| Angle of View: |
| |
59.8° to 2.0° (Wide-Tele) |
| Minimum Working Distance: |
| |
10 mm to 1500 mm (Wide-Tele) |
| Aperture Range: |
| |
F1.5 to F4.5 |
| Pan & Tilt |
| Pan Range: |
| |
360°endless |
| Pan Speed: |
| |
Configurable, from 0.1°/s to 300°/s
Preset Speed: 540°/s |
| Tilt Range: |
| |
Tilt: 0°~90° |
| Tilt Speed: |
| |
Configurable, from 0.1°/s to 240°/s
Preset Speed: 400°/s |
| Proportional Zoom: |
| |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
| |
300 |
| Patrol: |
| |
8 patrols, up to 32 presets for each patrol |
| Pattern: |
| |
4 pattern scans, record time over 10 minutes for each scan |
| Power loss recovery: |
| |
Support |
| Park Action: |
| |
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan /
Panorama scan
|
| PTZ Position Display: |
| |
ON/OFF |
| Freeze Frame: |
| |
Support |
| Smart-tracking: |
| |
Manual/ Panorama/ Intrusion trigger/ Line crossing trigger/
Region entrance trigger/ Region exiting trigger
Smart tracking when patrol between multiple scenarios
|
| Alarm |
| Alarm Input: |
| |
7 Inputs |
| Alarm Output: |
| |
2 channel relay output, with configurable alarm actions |
| Input & Output |
| Monitor Output: |
| |
1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC |
| Audio Input: |
| |
1 Mic in/Line in interface
Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10% |
| Audio Output: |
| |
1 Audio output interface
Line level, impedance: 600Ω |
| Network |
| Ethernet: |
| |
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: |
| |
1920×1080 |
| Main Stream: |
| |
50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720) |
| Image Compression: |
| |
H.264/MJPEG/MPEG4, H.264 encoding with Baseline/Main/High profile |
| ROI encoding: |
| |
Support 24 areas with adjustable levels |
| Audio Compression: |
| |
G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
| Protocols: |
| |
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP,
DNS, DDNS, NTP, RTSP, RTP,
TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
| No. of Simultaneous Users: |
| |
Up to 20 users |
| Three-Stream: |
| |
Support |
| User/Host Level: |
| |
Up to 32 users
3 levels: Administrator, Operator and User |
| Security Measures: |
| |
User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering |
| Client GUI |
| Date & Time Display: |
| |
Time: Week: Date, 6 formats on the Client |
| Client: |
| |
Support iVMS-4200 |
| Web Browser: |
| |
IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, support multi-language |
| General |
| RS-485 Protocols: |
| |
HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Menu Language: |
| |
English |
| Power Consumption: |
| |
100 VAC to 240 VAC, Max.: 60 W |
| Working Temperature/Humidity: |
| |
-40° C to 60°C (-40° F to 140° F) |
| Dimensions: |
| |
Φ 281 mm × 405 mm (11.06″ × 15.94″) |
| Weight (approx.): |
| |
Approx. 22 kg (48.5 lb) |
| Mount Option: |
| |
DS-1685ZJ-X Wall Mounting Bracket (Included);
DS-1686ZJ-X Pendant Mounting Bracket (Optional) |
