| Camera |
| Image Sensor: |
| |
1/3″ Progressive Scan CMOS |
| Signal System: |
| |
PAL/NTSC |
| Min. Illumination: |
| |
0.1 Lux @(F1.2,AGC ON),
0.28Lux @ (F2.0,AGC ON ),
0 lux with IR |
| Shutter time: |
| |
1/25(1/30) s to 1/100,000 s |
| Lens: |
| |
1.19mm, F2.0
Angle of view: 180°(wall mount), 360°(ceiling mount) |
| Auto Iris: |
| |
DC drive |
| Day& Night: |
| |
IR cut filter with auto switch |
| Wide Dynamic Range: |
| |
120 dB |
| Digital noise reduction: |
| |
3D DNR |
| Compression Standard |
| Video Compression: |
| |
H.264/MJPEG |
| Video bit rate: |
| |
32Kbps~16Mbps |
| Audio Compression: |
| |
G.711/G.722.1/G.726/MP2L2 |
| Dual Stream: |
| |
Yes |
| Image |
| Max. Image Resolution: |
| |
2048×1536 |
| Frame Rate: |
| |
Mode 1:
50Hz: 1×fisheye (1536×1536 ,20fps), 1×panoramic (1600×1200, 20fps),3×PTZ (800×600, 20fps)
60Hz: 1×fisheye (1536×1536, 20fps), 1×panoramic (1600×1200, 20fps),3×PTZ (800×600, 20fps)
Mode 2:
50Hz: 1×fisheye (2048×1536/1536×1536, 25fps) or 4×PTZ (800×600, 25fps)
60Hz: 1×fisheye (2048×1536/1536×1536, 30fps) or 4×PTZ (800×600, 30fps)
Mode 3:
50Hz: 1×Fisheye(1536×1536, 25fps) + 1×Fisheye(720×720, 25fps) + 3×PTZ(800×600, 12.5fps)
60Hz: 1×Fisheye(1536×1536, 30fps) + 1×Fisheye(720×720, 30fps) + 3×PTZ(800×600, 15fps)
Mode 4:
50Hz: 1×Panorama(1600×1200(ceiling, table, wall mount)/1600×600(wall mount)/1280×720(ceiling mount, wall mount),
25fps) + 1×Panorama(704×576, 25fps)
60Hz: 1×Panorama(1600×1200(ceiling, table, wall mount)/1600×600(wall mount)/1280×720(ceiling mount, wall mount),
30fps) + 1×Panorama(704×576, 30fps)
|
| Image Settings: |
| |
Saturation, brightness, contrast adjustable through client software or web browser |
| BLC: |
| |
Yes, zone configurable |
| ROI: |
| |
Support |
| Picture Overlay: |
| |
128 × 128, BMP 24bit, zone configurable |
| Network |
| Network Storage: |
| |
NAS (Support NFS,SMB/CIFS) |
| Alarm Trigger: |
| |
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis,
Tampering alarm, Network disconnect , IP address conflict, Storage exception
|
| Protocols: |
| |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| Security: |
| |
User Authentication, Watermark, IP address filtering, anonymous access,
flickerless, heartbeat, video mask
|
| System Compatibility: |
| |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
| Audio: |
| |
Internal Microphone and Speaker |
| Communication Interface: |
| |
1 RJ45 10M / 100M Ethernet interface |
| On-board storage: |
| |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
| |
Yes |
| General |
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
| |
12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: |
| |
Max. 12.18 W |
| Impact Protection: |
| |
IEC60068-2-75Eh, 50J; EN50102, IK10 |
| Weather Proof: |
| |
IP66 |
| IR Range: |
| |
15 meters |
| Dimensions: |
| |
164×152.8×43.8mm(6.46”x6.02”x1.72”) |
| Weight: |
| |
1400g |
| NOTE：: |
| |
* “-S” series support 1-ch audio I/O, 1-ch alarm I/O and 1-ch RS-485 interface |
