| Network |
| Ethernet: |
|
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: |
|
1920×1080 |
| Main Stream: |
|
50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720) |
| Sub Stream: |
|
50Hz: 25fps(704×576, 640×480,352×288); 60Hz: 30fps(704×480, 640×480,352×240) |
| Third Stream: |
|
50Hz: 25fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Compression: |
|
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG |
| ROI encoding: |
|
Support 2 areas with adjustable levels |
| Audio Compression: |
|
G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
| Audio Mode: |
|
OFF/Audio input/Audio output |
| Protocols: |
|
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP,
IGMP, ICMP, DHCP, PPPoE, Bonjour
|
| No. of Simultaneous Users: |
|
Up to 20 users |
| Three-Stream: |
|
Support |
| Mini SD Card: |
|
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| User/Host Level: |
|
Up to 32 users, 3 levels: Administrator, Operator and User |
| Security Measures: |
|
User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption,
IEEE 802.1x Port-Based Network Access control, IP address Filtering
|
| Hik-Connect: |
|
Support |
